| Specifications | Specifications | Specifications | ||||||
| The main parameters | Model | B66ZA4X | The main Functions | Audio input | Support | The main Functions | QR code &EZ | Support |
| Product name | Tuya outdoor PTZ | Volume adjustment | Support | Bluethooth | Support | |||
| Operation method | Tuya Smart | Watermark logo | Support | QR code &EZ | Support | |||
| Main chip | AK3918AV100P | TF card pop-up window function | Support | Calling bottom | Not Support | |||
| Sensor | SC3336 | ZOOM | Support | Audible alarm | Support | |||
| Resolution | 4MP | WDR | Support | Strong binding | Support | |||
| Lens | 4mm | Smart frame | Support | Network transmission | Support 2.4GHz wireless network; support WPA and WPA2 encryption | |||
| Infrared night vision | 10 meters black and white night vision | Insert the card to automatically start recording | Support | |||||
| Noise reduction | 3D digital noise reduction | Silent video | Support | Network protocol | TCP/IP,IPv4,DHCP,P2P； | |||
| Full color night vision | Support | Human detection | Support | Customized PID and APP device models | Support 2.4GHz wireless network; support WPA and WPA2 encryption | |||
| PTZ rotation angle | 351 degrees horizontal, 180 degrees vertical | Cry detection | Support | Power supply | DC5V 1A | |||
| The main Functions | Switch mode | Automatic | Privacy protection | Support | Operating temperature | ’-10~45 Degree | ||
| PTZ | Support | Area detection | Support | Working humidity | ≦95% | |||
| Audio input | Support | Buzzer | Support | Shell material | PVC | |||
| Two-way intercom | Support | Alarm area settings | Support | Color box size | ||||
| ONVIF | Not support | Siren | Support | Weight | ||||
| WIFI transmission | Support | Alarm trigger whistle/buzzer adjustment | Support | Installation method | On the Desk, hoisting, wall mounting | |||
| RJ45 network interface | Support | Audible alarm | Support | bracket | External bracket | |||
| POE power transmission | Not support | Cloud storage | Support | Google Home, Amazon Alexa voice linkage | OEM | |||
| Motion Detection | Support | Local storage | Support | |||||
| Humanoid detection | Support | Restore default with one click | Support | Resolution | HD：2560*1440； SD：640*360 |
|||
| Motion tracking | Support | Reset button | External | |||||
| Alarm linkage | Support | Light sensitivity | 0.1lux | Workflow | Main stream 1.5Mbps Sub stream 512Kbps | |||
| Alarm Notice | Support | Video encoding | H.265&H.264 | |||||
| Remote viewing/playback | Support | Video system | 1440P@20FPS | |||||
| Anti-flicker | Support | Video mode | HD/SD | |||||
| Screen flip | Support | Workflow | Main stream 1.5Mbps Sub stream 512Kbps | |||||
